W6000: R635-1.6W, G525-1.6W, B450-3W
◎Operation voltage:AC100-230V,50/60Hz
◎Power consumption: 700W max
◎Scan system: 40kpps scanner, max±30°Horizontal scan: 540° (16 bit precision scan) Vertical scan:270° (16 bit precision scan) automatic error correction reset function
◎Modulation: Analog
◎Animation laser beam diameter:10W laser beam diameter 6*6.5mm;6W laser beam diameter 3*6.5mm
◎Divergence:< 1.5mrad
◎Control mode: DMX512,auto, sound, master-slave, ilda, SD card
◎Control technology: ① RDM data bidirectional transmission ② temperature control system ③ DMX512 upgrade
◎DMX effect:pattern can output the function of unique blanking, strobe,rotation,movement,zoom, write in,speed and color etc.
◎Operating requirement: dry, less dust, 10~35℃(environmental temperature), will reduce the attenuation of the diode and extend the life of the light.
◎Application: disco, club, medium indoor venue, theatre, etc.
◎Packing: 50*39*66.5cm N.W/G.W:30KG/45KG
